The Rib (Triangle): In the Front View, it will look like a rectangle 6mm wide. In the Side View, it will appear as a triangle sloping from the top of the box to the base. Hidden Lines: Don't forget to use dashed lines for the internal 24x24 square hole and the side cutout when they are not visible from the outside. Spacing: Keep a consistent gap (usually 20mm) between your views to leave room for dimensions.
